INNO3D GeForce RTX 5090 X3

Minimum System Power Requirement (W) 1000W

Supplementary Power Connectors 4x PCIe 8-pin cables (adapter in box) OR 1x 600 W PCIe Gen 5 cable

Memory Clock 28Gbps

Standard Memory Config 32GB

Memory Interface GDDR7

Memory Interface Width 512-bit

Memory Bandwidth (GB/sec) 1792 GB/sec

Real-Time Ray Tracing Yes

Ray Tracing Cores 4th Generation, 318 TFLOPS

Tensor Cores 5th Generation, 3352 AI TOPS

NVIDIA Architecture Blackwell

Microsoft DirectX 12 Ultimate

NVIDIA DLSS 4

NVIDIA Ansel Yes

NVIDIA FreeStyle Yes

Bus Support PCI Express Gen 5

NVIDIA ShadowPlay Yes

OS Certification Windows 11 / 10, Linux, FreeBSDx86

NVIDIA Highlights Yes

NVIDIA G-SYNC™-Ready Yes

Game Ready Drivers Yes

NVIDIA Studio Drivers Yes

NVIDIA GPU Boost™ Yes

Vulkan API 1.4

OpenGL 4.6

NVIDIA Encoder 3x Ninth Generation

NVIDIA Decoder 2x Sixth Generation

Length 333

Height 137

Width 60

Multi Monitor up to 4

Maxmium Digital Resolution 4K at 480Hz or 8K at 165Hz with DSC

HDCP 2.3

Standard Display Connectors 3x DisplayPort 2.1b, 1x HDMI 2.1b
